Manufactured using a high-density overlay (HDO) of phenolic resin impregnated paper bonded to plywood, Formply is an ideal product for concrete formwork. Due to its A bond glue line, Formply can also be utilised in interior and exterior non-structural applications.
.."Manufactured using a high-density overlay (HDO) of phenolic resin impregnated paper bonded to plywood, Formply is an ideal product for concrete formwork. Due to its A bond glue line, Formply can also be utilised in interior and exterior non-structural applications."
※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※※
Standard: AS/NZS 6669
Structural rating: F14 - F22
Glue bond: A bond (Exterior)
Structural Applications: Concrete form-work, bridge building and any application requiring a known structural rating.
Non-Structural Applications: Multi purpose use, still utilising an exterior glue line including cabinetry and joinery.
Standard: AS/NZS 6669
Structural rating: F14 - F22
Glue bond: A bond (Exterior)
Structural Applications: Concrete form-work, bridge building and any application requiring a known structural rating.
Non-Structural Applications: Multi purpose use, still utilising an exterior glue line including cabinetry and joinery.
Specifications
| Parameter | Details |
| Construction： | all hardwood Eucalyptus |
| Standard： | AS6669 |
| Bond Type： | Melamine fortified urea formaldehyde Type B Bond |
| Overlay： | 60/165 Grams per Square Meter by Dynea |
| Surface Grade： | Class 2 and Class 3 |
| Edge-Sealing： | Water-Resistant Sealant coating in Grey Colour |
| Stress Grade： | F17 |
| Certificate： | Benchmark JAS-NZS |
| Length and Width： | +/- 0.5mm |
| Tolerance： | +/- 2% Overlay not Included Sheet Sizes |
| Thickness： | 17mm |
| Sheet Sizes： | 2400 x 1200; 1800 x 1200 |
| Formaldehyde Emission： | E1 or E0 |
| Chain of Custody： | FSC |
F14 Specifications
| Parameter | Details |
| Construction： | Eucalyptus plantation |
| Standard： | AS6669 |
| Adhesive： | Melamine fortified urea formaldehyde Type B bond |
| Sheet Size： | 2400x1200mm; 1800x1200mm |
| Thickness： | 17mm |
| Certification： | Benchmark JAS-ANZ |
| Off-form finish： | Class 3 |
| Pack size： | 50 sheets per pack |
| Stress Grade： | F14 |
| Chain of Custody： | FSC |
F22 Specifications
| Parameter | Details |
| Construction： | all birch |
| Standard： | AS6669 |
| Adhesive： | Phenol formaldehyde Type A bond |
| Sheet Size： | 2400x1200mm; 1800x1200mm |
| Thickness： | 17mm |
| Certification： | Benchmark JAS-ANZ |
| Off-form finish： | Class 2 and Class 3 |
| Chain of Custody： | FSC |
